AG-KOTE™

thermoset powder coatings

The unique formulation of these coatings, as well as their ability to cure at low temperatures, allows them to coat porous substrates with virtually no cratering, pitting or air bubbling.

OVERVIEW

The anti-gassing thermoset powder solution

Outgassing is a phenomena of entrapped gasses being released through a coating during the cure process. When this gas passes through the coating, it creates craters, pinholes or air bubbles.

These anomalies provide a path for moisture or corrosive materials through the coating and to the substrate.

AG-KOTE™ is a patented thermoset powder coating solution that minimizes the formation of craters, pinholes or air bubbles in the coating surface caused by gas or moisture released from porous substrates during curing.

AG-KOTE™ is a polyester-based coating formulated to be cured at temperatures as low as 160°C. It promotes energy savings and higher productivity without sacrificing the quality and properties of the coating.


MAIN FEATURES
  • Low temperature curing promotes energy savings and higher productivity when painting large objects.
  • Possibility to coat thin and thick material at the same time without colour and effect differences.
  • Excellent UV, chemical, and corrosion resistance.
  • Can be formulated with most Protech Group coatings.

PROVEN PERFORMANCE
PRE-TREATMENTFor steel and Aluminum–Phosphating or Zirconium
or other suitable surface treatment
APPLICATION CONDITIONSElectrostatic powder spray 40 to 120 kv
FILM THICKNESSFor normal usage 1.5 to 4.0 mils (Color and finish type related)
HARDNESSHB to 4H (Formulation related)
SPECIFIC GRAVITY1.2 to 1.75 (Color related)
COVERAGE160 to 110 ft² / lbs / mil at 100% efficiency (Color related)
BAKING SCHEDULEMETAL TEMPERATURE (Formulation Related)
8-10 minutes at 280ºF (138ºC) Super low temperature cure
8-10 minutes at 320ºF (160ºC) Low temperature cure
2-6 Minutes at 400 (205ºC) Fast Cure
7 minutes at 400ºF (205ºC) Regular cure
8+ minutes at 400F (205ºC) Slow cure

COLOR OPTIONS

Custom formulations

Talk to your coating expert regarding custom formulations to fit your exact needs.

Stock colors

Select one of the many stock colors that are readily available for processing.

Color reference chart

Get inspired from a broad range of standard colors. Request a RAL fan deck or ask one of our experts.


TROUBLESHOOTING

We stand by our products, even when things don’t go quite as planned. From cleaning and phosphating all the way to the final cured film appearance, we are here to help address your issues with proven solutions.

Contact our experts for tailored support.

Care and maintenance

To ensure the life of your asset is maximised, a simple and regular maintenance program should be implemented.

Contact our experts for specific tips and advice of cleaning.

Compliance

AG-KOTE™ can be formulated to be compliant with certain guidelines.

Ask our experts to see what different types of compliance, certification, or accreditation is available in your area.


TYPICAL APPLICATIONS

Commercial & Industrial

  • Street furniture
  • Store fixtures
  • Lighting
  • Fencing

Functional

  • Electronics
  • Valves & fittings
  • Rebar
  • Pipelines

white metal bridge close up
Stylized lantern with two shades in a city park, on a background of blue sky with clouds.
Steel picnic table close up in green.
